Direct correlation to NEMA combination cutout-arrester style
Fits Crossarm widths of 2-3/4in to 4in and heights of 4-1/8in to 5-3/8in
2-3/4in extension from crossarm face to mounting bolt
Bracket material is 3/8in x 2in
Mounting bolts are 3/8in x 1-1/2in and 3/8in x 2in
Crossarm bolts are 3/8in x 5in
Cutout-Arrester Bracket Specification:
Cutout-Arrester Bracket Structural design
Sturdy frame structure: usually made of high-strength metal materials, such as high-quality carbon steel or stainless steel, with excellent compression and deformation resistance, able to withstand the weight of the circuit breaker and possible external force impact.
Flexible installation method: According to different application scenarios and circuit breaker models, a variety of installation holes and connection methods are designed. Common ones are bolt connection, clip connection, etc., which are convenient for users to install quickly and conveniently according to actual needs, and can be adapted to various specifications of circuit breakers and different installation surfaces.
Reasonable space layout: Taking into full consideration the external dimensions and heat dissipation requirements of the circuit breaker, the structural design of the bracket can provide sufficient space for the circuit breaker, ensure smooth air circulation around it, facilitate heat dissipation, and avoid affecting the performance and life of the circuit breaker due to overheating.
Buy Cutout-Arrester Bracket From Yokelink
Equipment brackets, offered by the Yokelink brand, are designed for pole and crossarm mounting of components that includes cutouts, arresters, cable terminators, transformers, switches, capacitors and regulators. Options include single phase and three phase style brackets for crossarm or pole mounting; with many brackets offer in either steel or aluminum construction.
